Recuperative Solid Sodium Silicate Glass Furnace

FOB Reference Price:Get Latest Price
US $30,000-5,000,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Glass melting furnace
Usage:
Melting Furnace
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Longtai
Model Number:
LT-GGL
Voltage:
User's
Power(W):
-
Dimension(L*W*H):
Based on the melting capacity
Weight:
Based on the melting capacity, 325(t)
Certification:
ISO9001:2008 CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Name:
Recuperative Solid Sodium Silicate Glass Furnace
Fuel:
Natural gas,coal gas,coal,oil,coke gas
Final product:
Sodium silicate,water class
Crafts:
Melting furnace
Shape:
Heat exchange furnace
Raw material conveying method:
Machinery conveying,pneumatic conveying, crystallizer conveying
Temperature range:
1200-1560(℃)
Material:
Refractory material and metal material
Production capacity:
0.79(t/h)
Supply Ability
Supply Ability:
5 Set/Sets per Year
Packaging & Delivery
Packaging Details
As customer's request
Port
Qingdao
Lead Time :
70-100 days after receiving deposit

Features and advantage:

1.Total insulation;

2.Deep melting pool, big aspect ratio,high flame space;

3.Equipped with Pre-combustion room, stable and strong flame;

4.Throat with offset,double flow mouth with lift (easy to change raw meterial and adjust formula, flexible);

5.Glass liquid level controlled by the automatic control system(accuracy between ±0.2mm);

6.The furnace is equipped with two burners, which work alternately every 30 minutes, using PLC control system;

7.Saving energy, low cost ;

8.Compact structure, cover small area.



Name

Specification

Melting Area(m2)

Fuel: natural gas

Melting Rate(K)

Energy

Consumption

(CAL/KG)

Melting

Capacity

(T/DAY-24H)

Automatic

Control System



Total Weight(T)

Refractory&Steel

Heat exchange

 furnace

LT-HRL-16

1.2

2400

19

PLC

325



_01_02_03_04_05
