50T Solid Sodium Silicate Product Line With Automatic Batching System

FOB Reference Price:Get Latest Price
$30,000.00 - $5,000,000.00 / Sets | 1 Set/Sets sodium silicate furnace (Min. Order)
Report Suspicious Activity
Quick Details
sodium silicate furnace
Melting Furnace
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Model Number:
Furnace type:
sodium silicate line
Product Name:
sodium silicate product line
12 months
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
10 Set/Sets per Year furnace
Packaging & Delivery
Packaging Details
export packages
Lead Time :
Product Description

      High Efficiency Gas Sodium Silicate Product Line


Solid Sodium Silicate Plant:

Horseshoe Flame Solid Sodium Silicate Furnace Production Line
Furnaces typeRegenerative furnace and recuperative furnace.
Melting capacity1-160 tons per 24 hours, normal melting rate: 1.4-2.0.
Fuel typeNatural gas, lpg,coke gas, coal gas, heavy oil or light diesel and so on.
Design temperature1350-1580℃
SpecificationValid melting area is 1-80m2, part enhanced insulation and full thermal insulation.
RegeneratorArranged in Siemens or octagonal cylindrical brick checker type, single or double route.
Cooling methodDirect water quenching or chain plate molding machine
Advantages(1) More scientific and energy saving, more economical and efficient,
(2) Small covering area, and U-shape flame will lead to high thermal efficiency;
(3) Deep melting tank, high flame space, and large aspect ratio, higher melting
storage,pre-combustion chamber set will lead to perfect heating performance;
(4) Offset hole fluid flow mouth and a liftable flow mouth makes it more convenient
and flexible to change the formula.
OthersPLC automatic control system is adopted to realize the automatic reversal of primary air, secondary air and gas.
The most advanced technology of hermetic fixed amount continuous charging and continuous automatic excavating are applied.
Application of
sodium silicate:
Silica-alumina catalyst, silica gel, silica hydrated, sodium metasilicate, detergent,
dyeing and bleaching, casting materials, soil curing agent, refractory, corrugated
board, waterproofing, silicon fertilizer, desiccant, carton binder etc.


Packaging & Shipping

 The refractory will be packaged with wooden pallet.20GP will be used for refractory,40OT will be used for equipments.

Our Services

 We could provide furnace turkey project,furnace assentment and maintenance,furnace consultation.

Company Information

 We own:

1.Advanced and mature technology    2.More than 20 years designing and building experience

3.Professional construction team         4.Excellent oversea successfully cases

5.Stable after-service                              6.ISO9001 certficate


1.What is the shape of the solid sodium silicate?

Re:There are two shapes of solid sodium silicate,one is lump,nearly pyramid.Another is granule,nearly cullet.


2.What is the raw material to produce sodium silicate?

Re:Most customers choose Na2CO3 and quartz sand.


3.How long will it take to finish a sodium silicate production line?

Re:For example,one 30tons production line from the preparations to trial production will take about 200-220days.


4.For the formal quotation,what shall be informed?

Re:Furnace capacity one day,Fuel,Raw material,Sodium silicate shape/cooling method.
